Model 1250 Digital RF Memory

Product Details

The Eastern OptX Model 1250 Radar Target Simulator is a digital propagation path replicator. The 1250 will produce a moving target with appropriate target cross-section, propagation loss, with a dynamic range of over 50 dB. The 1250 operates with pulsed, frequency hopping, or CW radars and with any encryption or modulation scheme.

Features

• Propagation loss replication
• I/O Antenna Gain Input
• Longitude, Latitude, and Altitude Target Input Option
• Interferer Injection (Jammer)
• Moving Target Scenario Generator
• Programmable (SCPI Commands)
• Bandwidth (limited by A/D , ~ 1 GHz)
• Microsecond switching speed
• Multipath (Clutter)
• Interferer Generator/Injector
• Radar Cross-Section Input
• Multiple Target Output
• Input/Output Signal Measurement and Display

Applications

• Radar Testing
• Satellite and Radio Testing, GPS Testing
