ADC-2500 Series Pressure Source

Product Details

Calibrator Pressure Source

Raptor offers oil-less compressors offer outstanding performance and value for those who demand the most quiet, dependable clean air systems. All units come equipped with a tank, pressure regulator with built-in moisture trap and line pressure gauge, tank pressure gauge, safety valve, air intake filter and motor cooling fan. Compressors also feature a built in desiccant dryer, providing clean, dry air for the ADC-2500 Series or other test equipment.
  • Provides clean, dry, regulated pressure source
  • Max Pressure of 100 PSI (7 bar) suitable for many applications
  • 8ft Pressure Source Hose included with each compressor
  • 115 VAC 50-60 Hz Model , P/N: ADC-2500-PRES-115
    NSN: 6830-01-653-2523
  • 220 VAC 50-60 Hz Model , P/N: ADC-2500-PRES-230

CompressorThe oil-less compressors offer outstanding performance and value for those who demand the most quiet, dependable clean air systems. All units come equipped with a tank, pressure regulator with built-in moisture trap and line pressure gauge, tank pressure gauge, safety valve, air intake filter and motor cooling fan. Compressors also feature a built in desiccant dryer, providing clean, dry and particle free air at – 40°F dew point. The compressor includes an 8 ft pressure hose assembly for direct connection the the ADC-2500 Series rear panel Pressure Input. Other features include:

• Horsepower: 0.80
• Power: 115 VAC 50-60 Hz or 220 VAC 50-60 Hz available
• Output: CFM 4.4 CFM (110 liters/min)
• Max Pressure: 100 PSI (7 bar)
• Pressure: 80-100 PSI (6-7 bar)
• Noise Level: 57 db/A
• Internal Tank Size: 1.57 gallons (6 liters)

adc-2500-scene
